Sludge Dewatering Filter Fabric Belt
Sludge Dewatering Filter Fabric Belt
Product Introduction
Sludge dewatering filter fabric belt mainly be used in belt type filter press, the rubber belt type vacuum filter, horizontal vacuum belt filter. Apply to the municipal domestic sludge, various industries of sludge filter, paper pulp squeezing, concentrated juice squeezing and other special industries use.
Sludge dewatering filter fabric belt is herringbone design, as a result of the sludge and mesh belt off quickly, not sticky mud, a large number of out of the mud, high efficiency, easy to clean, convenient and fast connection.
Product Details
Product Data
|
Type |
Filament diameter(mm) |
Density(lines/cm) |
Weight (kg) |
Thickness (mm) |
CFM(125pa) |
Air permeability (100pa) |
||
|
warp |
weft |
warp |
weft |
|||||
|
YLW15803 |
0.66 |
0.8 |
15.2 |
5.8 |
1.26 |
2 |
360 |
5760 |
|
YLW16903 |
0.7 |
0.9 |
16.3 |
5.15 |
1.6 |
2.1 |
425 |
6800 |
|
YLW16903 |
0.68 |
0.9 |
16.3 |
5.2 |
1.6 |
2 |
425 |
6800 |
|
YLW16904 |
0.7 |
0.9 |
16.3 |
5 |
1.4 |
2.35 |
645 |
10320 |
|
YLW22903 |
0.5 |
0.9 |
23 |
5.5 |
1.4 |
1.9 |
530 |
8500 |
|
YLW24908 |
0.5 |
0.9 |
24.8 |
7.1 |
1.48 |
2.1 |
460 |
7360 |
|
YLW181003 |
0.55 |
1.0 |
18.1 |
5.3 |
1.3 |
2.1 |
525 |
8400 |
|
YLW181005 |
0.65 |
1.0 |
18.1 |
5.65 |
1.65 |
2.3 |
490 |
7840 |
|
TSW181005 |
0.65/0.35 |
1.0 |
18.1 |
5.65 |
1.72 |
2.32 |
470 |
7600 |
|
YLW24708 |
0.5 |
0.7 |
24.3 |
9.8 |
1.3 |
1.8 |
340 |
5441 |
|
YLW241008 |
0.5 |
1.0 |
24.3 |
7.1 |
1.6 |
2.25 |
399 |
6380 |
|
YLW25608 |
0.48 |
0.6 |
25 |
11.1 |
1.2 |
1.69 |
318 |
5091 |
|
YLW28506 |
0.35 |
0.5 |
28 |
16 |
0.9 |
1.05 |
112 |
1760 |
|
YLW29506 |
0.35 |
0.5 |
29.2 |
12.8 |
0.82 |
1.08 |
253 |
4030 |
|
YLW14804 |
0.66/0.65 |
0.8 |
14.5 |
6.7 |
1.3 |
1.9 |
431 |
6900 |
|
YLW12804 |
0.8 |
0.8 |
12.4 |
4.8 |
1.38 |
2.26 |
645 |
10430 |
|
YLW121004 |
0.66/0.35 |
1.0 |
12.7 |
5.7 |
1.31 |
1.82 |
505 |
8000 |
Application
Filtering industry
Suitable for belt filter press
